Woven Bag Shredder

Product Overview

Woven bag shredder This shredder is suitable for new films, woven bags, fishing nets, and other multi-purpose woven bag shredders; it can be used for the recycling and shredding of waste agricultural films, packaging films, greenhouse films, ton bags, space bags, food bags, cement bags, waste fishing nets and other raw materials;

Product Performance

• Power distribution box: The transmission gears have undergone forging processing and high-frequency quenching treatment, ensuring a relatively long service life
• Fixed blade: The fixed blade serves to guide the material and prevent it from being brought back after being crushed, as well as to clean the blade
• Fixed tool holder: It serves to fix the fixed tool, optimize the tool changing function, and make tool maintenance and replacement more convenient.
• Sealing: The unique sealing structure can fully protect the machine even when handling liquid materials
• Bearing housing: The bearing housing adopts a assembled type, which enables quick removal of the tool shaft, blades, sealing system, bearings and other components, making it easy to maintain and replace the tools.
• Moving tool: The tool is made of D2 and undergoes multiple heat treatments for overall quenching and tempering. The hardness and toughness of the tool material are the same both inside and out, featuring high strength and a long service life. The tool can be reused. Tools with blunt edges and rashes ground off in proportion on the basis of the original thickness can still be used.
• Tool shaft: Made of high-strength material, it undergoes quenching and tempering followed by high-frequency treatment and then is milled into a hexagonal shape, which is in line with the force on the tool and is not afraid of damage.
• The feeding hopper and frame can be reasonably designed according to customer requirements.

Working Principle

The new multi-purpose woven bag shredder for films, woven bags, fishing nets, tires, etc. adopts dual-axis independent drive, so that the materials are pressed accordingly during production to achieve the automatic feeding function. The unique knife shaft structure and four-corner rotating knives will not cause the shaft to be entangled or the equipment to be stuck during the low-speed and high-torque production process, thereby improving production efficiency. The equipment is suitable for crushing various tough and high-viscosity materials. It has many advantages in production, environmental protection, recycling, etc.

Technical Parameters
