Product Overview

  • The silo has an overall circular motion, high shredding efficiency, and no material jam.
  • The spindle is an integral fastener, which is automatically processed by the machining center and will never break.
  • The transmission parts are connected by couplings to reduce vibration, protect the spindle and reducer, and do not lose force.
  • The electronic control system is PLC autonomous

Working Principle

Scrap steel shredder is a processing method that uses a shredder to crush scrap steel and uses a sorting system to sort the shredded scrap steel to obtain pure scrap steel. Its working principle is that under the continuous drive of a high-speed, high-torque motor, the hammers on the shredder rotor take turns to hit the scrap steel entering the cavity. Under the strong impact, the scrap steel is torn and squeezed into broken steel of a certain specification, and then processed by the sorting equipment to obtain broken steel with higher purity.

Technical Parameters

Device model

Feed port(m)

Yield(t/h)

Main motor power(KW)

Matching transformer

200KW

1.4

3-5

200

250KVA

2500KW

1.4

5-*7

250

315KVA

280KW

1.6

5-8

280

400KVA

315KW

1.6

6-8

315

400KVA

450KW

1.6

7-11

450

630KVA

750KW

1.8

12-16

750

10KV high pressure

900KW

2.2

15-20

900

10KV high pressure

2000KW

2.5

20-40

1600

10KV high pressure

3000KW

2.5

40-60

2250

10KV high pressure

4000KW

2.6

50-80

2950

10KV high pressure

4500KW

2.7

55-90

3300

10KV high pressure

6000KW

2.7

80-120

4400

10KV high pressure
